BSWA 308/309 BSWA Technology Co., Ltd
84
2C 30 33 38 2E 30 2C 30 33 38 2E 30 2C 30 33 38 2E 30 2C 30 33 38 2E 30
2C 30 33 38 2E 30 2C 30 33 38 2E 30 2C 30 33 38 2E 30 2C 30 33 38 2E 30
2C 30 33 38 2E 30 2C 30 33 38 2E 30 2C 30 33 38 2E 30 2C 30 33 38 2E 30
2C 30 33 38 2E 30 2C 30 33 38 2E 30 2C 30 33 38 2E 30 2C 30 33 38 2E 30
2C 30 33 38 2E 30 2C 30 33 38 2E 30 2C 30 33 38 2E 30 2C 30 33 38 2E 30
2C 30 33 38 2E 30 2C 30 33 38 2E 30 2C 30 33 38 2E 30 2C 30 33 38 2E 30
2C 30 33 38 2E 30 03 6C 0D 0A
CUSp1_p2_p3_p4: Set Custom Measure
Instruction
P1
P2
P3
P4
Explanation
CUS
p1: Group;
Range: 1~14
p2: Filter;
0=A;
1=B;
2=C;
3=Z
p3: Detector;
0=Fast;
1=Slow;
2=Imp.
p4: Mode;
0=SPL;
1=SD;
2=SEL;
3=E;
4=Max;
5=Min;
6=Peak;
7=LEQ;
8=LN1;
……
17=LN10
ASCII
C
U
S
1
0
0
0
Hex
43H
55H
53H
31H
30H
30H
30H
Byte
1
1
1
1~2
1
1
1~2
Return
ACK / NAK
Example: set custom measurement of group 1 to B-weighting, Fast, Peak.
02 01 43 43 55 53 31 20 31 20 30 20 36 03 20 0D 0A
Return: ACK
02 01 06 03 06 0D 0A
Default value of each group in custom measurement (parameter with * is actually useless):
Filter
Detector
Mode
Meaning
Custom 1
0
0
7
A, Fast*, LEQ
Custom 2
0
0
8
A*, Fast*, LN1
Custom 3
0
0
12
A*, Fast*, LN5
Custom 4
0
0
16
A*, Fast*, LN 9
Custom 5
0
0
4
A, Fast, Max
Custom 6
0
0
5
A, Fast, Min
