BSWA 308/309 BSWA Technology Co., Ltd
86
Example: set the Timer as switch: ON, start day: Ignore, start hour: 12:00, repeat period: 1m.
02 01 43 54 49 53 31 20 30 20 31 32 20 30 20 31 03 0E 0D 0A
Return: ACK
02 01 06 03 06 0D 0A
TIS?: Query Timer Setting
Instruction
Parameters
Explanation
TIS
Query parameter: ?
ASCII
54H
49H
53H
?
Hex
1
1
1
3FH
Byte
54H
49H
53H
1
Return
Return Timer setting
Example: query Timer setting.
02 01 43 54 49 53 3F 03 32 0D 0A
Return: Timer setting is switch=OFF, start day=Ignore, Start Time=12:00, Repeat period=1m.
02 01 41 30 2C 30 30 2C 31 32 3A 30 30 2C 30 31 03 65 0D 0A
LDNp1_p2_p3_p4_p5_p6_p7_p8: Set Lden Period
Instruction
P1
P2
P3
P4
P5
P6
P7
P8
Expla
natio
n
LDN
p1: Day
hour;
0-23=0h
-23h
Default:
CHN: 6
Others:
7
p2: Day
minute;
0-59=0
min-59
min
Default:
0
p3:Even
hour;
0-23=0h
-23h
Default:
CHN: 22
Others:
19
p4:Even
minute;
0-59=0
min-59
min
CHN: 1
Others:
0
p5:Even
Penalty;
0-99.9=
0-99.9d
B
Default:
5
p6:Night
hour;
0-23=0h
-23h
Default:
CHN: 22
Others:
23
p7:NIght
mintue;
0-59=0
min-59m
in
Default:
0
P8:Nigh
t
Penalty;
0-99.9=
0-99.9d
B
Default:
10
ASCII
L
D
N
6
0
22
1
5
22
0
10
Hex
4CH
44H
4EH
36H
30H
32H,32
H
31H
35H
32H,32
H
30H
31H,30
H
Byte
1
1
1
1~2
1~2
1~2
1~2
1~4
1~2
1~2
1~4
Retur
n
ACK / NAK
Example: set the day time 5:32, evening time 21:52, evening penalty 6.3, night time 20:45,
night penalty 6.2
02 01 43 4C 44 4E 35 20 33 32 20 32 31 20 35 32 20 36 2E 33 20 32 30 20 34 35
20 36 2E 32 03 17 0D 0A
