C−LRV lift control valve Product description
19/92
300−I−9010212−E−10/08.08
0
2.5
5
7.5
10
12.5
15
400 450 500 550 600 650 700 750 800 850 900 950 1000
R1000
C−LRV 700
A
B
Flow ring (R)
Spool K 1001
DOWN (Z−T)
UP (P−Z)
Legend A
B
Pressure drop [bar] Min. required dyn. pressure
Flow rate Q [l/min.]
300 cSt (HLP 46)
75 cSt (HLP 46)
