C−LRV lift control valve Operation
73/92
300−I−9010212−E−10/08.08
Setting "K6/K7/K8 acceleration"
S Only operative with auxiliary speeds (K6, K7, K8)
S Higher value: greater acceleration, i.e. shorter acceleration distance
S Setting range: 0.30–5.00V/s
S Standard K6: 0.80V/s
S Standard K7: 1.20V/s
S Standard K8: 1.60V/s
Setting "K6/K7/K8 speed"
S Fast speed is reduced with K6, K7, K8
S Higher value: faster travel speed
S Setting range: 20–100% of fast speed
S Standard K6: 20%
S Standard K7: 30%
S Standard K8: 40%
Important: only operative with fast travel speed
Setting "K6/K7/K8 deceleration"
S Only operative with auxiliary speeds (K6, K7, K8)
S Higher value: greater deceleration, i.e. shorter deceleration distance
S Setting range: 0.30–5.00V/s
S Standard K6: 1.20V/s
S Standard K7: 1.80V/s
S Standard K8: 2.40V/s
Setting "Decel. emergency"
S Only operative for emergency stop (reasons for emergency stop:
activation of SIU−1, timeout error, fault)
S Higher value: greater deceleration, i.e. shorter deceleration distance
S Setting range: 5.00–10.00V/s
S Standard: 10.00V/s
Setting "Pulsation sol."
S Higher value: higher solenoid pulse frequency (dither)
S Setting range: 120–220Hz
S Standard: 220Hz
