L3 Display Screen
BLADE
SPEED
4250rpm
FEED
RATE
.64in/min
DISTANCE
REMAINING
1.00in
CUTTING
CYCLE
ON
DRESS
BLADE
OFF
IMPERIAL
UNITS
SELECT
ENGLISH
LANGUAGE
L3
L3 Display Screen Commands
Button [1] CUTTING CYCLE starts, stops, and pauses the cutting cycle.
Button [2] DRESS BLADE sets the correct blade-dressing parameters and activates the
automatic dressing mechanism (if attached).
Button [3] UNITS toggles between METRIC and IMPERIAL units of measure.
Button [4] LANGUAGE allows the operator to select a language from the list. The
languages currently available are:
 English
 French
 German
 Spanish
 Portuguese
 Japanese
 Chinese
 Korean
Button [5] Scrolls the LCD Screen between Screen L3, Screen L4, Screen L1, and Screen
L2.
