13
INPUTS AND OUTPUTS
There are no actual inputs or outputs on the ARC Plus SL chassis. I/O is provided through a wide range of IP
connected Plus-X or PlusConnect devices. In addition, virtual channels can be derived from a combination of
existing channels, constants and mathematical formulas. The SNMP Plus option enables direct control and
monitoring of a wide variety of SNMP-enabled devices. Up to 256 channels each of meters, statuses and command
pairs can be configured on an ARC Plus SL.
PLUS-X ETHERNET I/O
The Plus-X line of Ethernet I/O devices offers a variety of channel configurations, making it possible to have a
combination of inputs and outputs that meets your needs without purchasing excess capacity. For a complete list
of Plus-X devices, visit: http://www.burk.com/products/Facilities-Control-1/ARC-Plus-SL-4.
Plus-X devices include:
➢ Plus-X Integrated Input Unit
➢ Plus-X Integrated Command Relay Unit
➢ Plus-X 300
➢ Plus-X 600
➢ Plus-X EM Series Environmental Monitors
➢ Plus-X AC-8
➢ Plus-X IP-8 Adapter
➢ Plus-X GSC Adapter
➢ Plus-X RP-8 Adapter
For specific information on installing and configuring your Plus-X accessories, refer to the manual for your product.
Manuals are available online at www.burk.com.
PLUSCONNECT™ DIRECT TRANSMITTER INTERFACES
The PlusConnect series of direct transmitter interfaces allow a direct, digital connection to many popular models
of transmitters without requiring parallel wiring. For a complete list of PlusConnect models and the transmitters
they support, visit http://www.burk.com/products/Facilities-Control-1/PlusConnect-supTMsup-47.
To install your PlusConnect, follow the instructions in the PlusConnect instruction manual. The installation
procedure is similar to installing any Plus-X Ethernet I/O device.
