55
METER CHANNEL SOURCE
On the Meter Channels tab, click the […] icon under the Source heading to configure the source for this channel.
There are five options:
Selected by default. Indicates that a meter
channel is not in use.
This option allows you to map a Plus-X
channel. This is the most common
selection.
Calculates a value for this channel. Click or
turn to
VIRTUAL Channels for instructions.
Set by a macro
Using an SNMP Parameter as a Meter
Channel Source
This option allows a macro to set this
channel’s value. To assign the value, use
the Set command in a macro (Click or turn
to MACRO EXPRESSIONS) or in
Jet™ Active Flowcharts in AutoPilot®.
This option instructs the ARC Plus to
populate the meter channel with data
retrieved from an SNMP-enabled device.
See
