Type 2000
Installation
english
12
5.4.2 Pressure ranges
Actuator material Actuator size [mm] Max. Pilot pressure
[bar]
PA ø40...ø100 10
ø125 7
PPS ø40...ø80 10
ø100...ø125 7
Tab.6: Maximum pilot pressure
5.5 Mechanical data
Actuator size See type label
Installation position any, preferably actuator face up
Materials and ports
see data sheet or operating instructions
6 INSTALLATION
6.1 Safety instructions installation
DANGER!
Risk of injury from high pressure and discharge of medium.
▶ Before working on the device or system, switch off the pres-
sure. Vent or drain lines.
WARNING!
Risk of injury due to improper installation.
▶ Only trained technicians may perform installations.
▶ Perform installations with suitable tools only.
WARNING!
Risk of injury due to unintentional activation of the system and
uncontrolled restart.
▶ Secure plant to prevent unintentional activation..
▶ Ensure that the plant starts up in a controlled manner only.
DANGER!
For control function I: Danger due to the control pressure fail-
ing.
If the control pressure fails, the valve remains in an undefined
position.
▶ For a controlled restart, pressurize the device with control
pressure and then connect the medium.
