Maintenance, cleaning
Replacing packing gland
PEEKspindleguide(seriesproductionstatusuptoApril2012):
→ Unscrew the spindle guide with the aid of the installation
wrench
13)
andanopen-endwrench.
VAspindleguide(SeriesproductionstatussinceApril2012):
→ Unscrewspindleguideusingamodiedsocketwrench
13)
.
SP22:
→ Unscrew the VA spindle guide with the aid of an open-end
wrench.
Packinggland
PEEK
spindleguide
Spindle
Installationtool
Packingglandtube
Seriespro-
ductionstatus
uptoApril2012
Fig. 30: Replacing packing gland (PEEK spindle guide)
13) The installation wrench or modied socket wrench
is available from your Bürkert sales oce.
Packinggland
VAspindleguide
Spindle
Packingglandtube
Hexagon
Series
productionstatus
sinceApril2012
Fig. 31: Replacing packing gland (VA spindle guide)
Packinggland
Spacer
Spindle
Packingglandtube
SP22
VAspindleguide
Fig. 32: Replacing packing gland SP22
