Burkert 8793 - Connection and Start-Up of the Remote Sensor Type 8798

45
Installation
Type 8792, 8793
english
12.4.2. Connection and start-up of the Remote Sensor Type 8798
WARNING!
Risk of injury from improper start-up.
▶ Start-up may be carried out by authorised technicians only and with the appropriate tools.
Risk of injury from unintentional activation of the system and an uncontrolled restart.
▶ Secure system from unintentional activation.
▶ Following assembly, ensure a controlled restart.
→ Connect the 3 or 4 wires of the sensor cable to the designated screw-type terminals of type 8792/8793.
Connection of screw-type terminals: See chapter “15.2.4. Terminal assignment for external position sensor
(for remote model only)”, page 55.
Connection of M8 circular connector (only for PROFIBUS and DeviceNet): See chapter PROFIBUS “29.5”,
page 190 / DeviceNet “32.5”, page 209.
→ Attach Remote Sensor on the actuator.
The correct procedure is described in the brief instructions for the Remote Sensor.
→ Connect compressed air to Type 8792/8793.
→ Connect Type 8792/8793 pneumatically to the actuator.
→ Switch on operating voltage to the Type 8792/8793.
→ Run the X.TUNE function.
