Start-Up
Operating structure:
*
ENTER
INPUT
INPUT
OK
OK
EXIT
SP-SCALE
SPmin
SPmax
Input upper process set-point
value
Input lower process set-point
value
*
Figure 40: Operating structure SP-SCALE
Scaling process set-point value SETUP → SP-SCALE:
Key Action Description
/ Select SP-SCALE
ENTER
Press
The submenu options for scaling of the process set-point value are
displayed.
/ Select SPmin
INPUT
Press
The input screen is opened.
/
Increase value
<–
Select decimal place
Set scaling value (lower process set-point value).
The value is assigned to the smallest current or voltage value of the
standard signal.
OK
Press
Return to SP-SCALE.
/ Select SPmax
INPUT
Press
The input screen is opened.
/
Increase value
<–
Select decimal place
Set scaling value (upper process set-point value).
The value is assigned to the largest current or voltage value of the
standard signal.
OK
Press
Return to SP-SCALE.
EXIT
Press
Return to SETUP.
Table 43: SP-SCALE; scaling process set-point value
If the submenu is left by pressing the left selection key
ESC
, the value remains unchanged.
