TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
24
the heater operates for 3 minutes , and
the main fan is turned on at 20% of its
capacity and operates for 4 minutes (the
heater connues to work). If upon the
expiraon of that period the photosensor
detects the presence of stable ame, the
burner enters into operang mode. If no
stable ame is present, the burner feeds
in pellets again and repeats the process.

NOTE! Fan B/E 20/1 is a set up
forthemainfanat20%andset
upforthefanforfumegases1%
(ifthereisinstalled).Fanforthe
fume gases must be connected
totermonalFSG(seeshceme6).
Select the desired opon using the
navigaon arrows. Use the „Enter”
buon to open the next parameter. Use
the buon to open the next page of
the menu.
9.3.5.BurnLevel
The burner has
three main levels of
burning (three
main output modes
of operaon). Use
this menu to set the temperature
dierences at which the burner will shi
from higher output mode to lower (step
modulaon).
Example: We have set maximum
temperature of 85°С. Upon reaching
77°С, the burner will shi down to lower
mode of operaon (two ames). Upon
reaching 82°С, the burner enters into sll
lower mode of operaon (one ame).
Upon reaching 85°С, the burner enters
into suspend mode (Suspend).
Select the desired opon using the
navigaon arrows. Use the „Enter”
buon to open the next parameter. Use
the buon to open the next page of
the menu.
9.3.6. SetupofburningLevel
This submenu
allows you to adjust
the parameters of
the main mode of
operation
Maximum output of the burner. It is
indicated by three ames .
You can modify the pellet quanty
(Feed), me interval at which these
pellets are fed (Cycle) and fan output as a
percentage value (FAN).
Example: with the period set at 20
seconds, the pellet auger runs for 7,4
seconds feeding pellets in the burner,
and is o for 12,6 seconds.
Select the desired opon using the
navigaon arrows. Use the "Enter"
buon to open the next parameter. Use
the buon to open the next page of
the menu.
In this submenu
you can adjust the
parameters of the
medium output
mode of operaon
of the burner.
It is indicated by two ames .
We recommend to set at 50% of the main
mode.
You can modify the pellet quanty (Feed)
and fan output as a percentage value
(FAN).
Select the desired opon using the
navigaon arrows. Use the „Enter”
buon to open the next parameter. Use
