Operating the Unit
4326 9562-007 2-13
2. Slide documents forward to the end of the feeder bay - printed sides face the side
of the unit, not the feeder flag.
Caution
If feeding more than one item, do not slide or push items into the unit past the
end of the feeder bay.
There is an insertion icon on the outer cover of the unit that shows the location of
the end of the feeder bay.
Bottom edges of the documents should touch and be aligned with the feeder
floor.
To Next Page
