Cleaning the Unit
4326 9562-007 3-3
The SmartSource Series Starter Kit (supply order number 75-0820-995) includes cleaning supplies
as well as replacement items. Table 3-3 shows the contents of the Starter Kit. (Section 4 of this
guide has complete information on all replacement items.) All of the items in this kit can be ordered
separately.
Table 3-3 SmartSource Series Starter Kit
Item
Quantity
Track Clearing Spatula
1 package of 5
Image Glass Cleaning Pads, pre-
saturated with isopropyl alcohol
1 package of 80
Ink Jet Cartridge and Ink Pad Kit
1 kit, includes 1 cartridge and 1 ink pad
Feeder Roller and Separator Kit
1 kit, includes two feed rollers and one separator
assembly
Pocket Fingers
1 package of two fingers
Detailed Cleaning Sequence
Follow these procedures, in the order that they are presented in this section, to clean the unit:
 Turn the unit off
 Remove the top inner and outer covers
 Remove the front image camera removable wall
 Remove the franker roller (if present) and the rear image camera removable wall
 Clean the rear image camera removable wall (and, if necessary, replace the ink pad)
 Remove staples, paper clips, and visible debris from the track
 Blow air along the entire track (paper path) with a micro-duster
 Clean the front and rear image glass and the fixed rear image camera wall
 Clean ink off the endorser cartridge and cartridge housing (as needed to maintain print quality –
omit this procedure if print quality is acceptable)
