Busch-Jaeger 1098 U-101 - Technical Data

Technical data
Product manual 2CKA001473B8291
│11
5 Technical data
Nominal voltage:
230 V AC ±10%, 50 Hz
Nominal power:
1098 U-101
Change-over
contact/normally
open contact
closed while de-
energized
(connection 1)
10 (4) A
Change-over
contact/normally
closed contact
open while de-
energized
(connection 2)
5 (2) A
1098 UF-101
Change-over
contact/normally
open contact
closed while de-
energized
(connection 1)
16 (2) A
Change-over
contact/normally
closed contact
open while de-
energized
(connection 2)
5 (2) A
Control range: 1098 U-101
5°C - 30°C
1098 UF-101 10°C - 50°C
Opening of change-over contact:
< 3 mm µ
Power reserve: Approx. 10 h at 25°C
Memory locations: Maximum of 28 switching times
Shortest switching interval: 5 minutes
Ambient temperature: 0°C - 30°C
Protection type: IP 20
Regulation EN 60 730-2-9
Input:
1098 UF-101
External remote sensor
Summer/winter time: Automatic changeover
Mode of operation (DIN EN 60730-1): 1B
Degree of contamination (DIN EN 60730-1): 2
Rated surge voltage (DIN EN 60730-1): 4000 V
