7. List of Replacement ParTS
ID # Part # Part Name
1–10 mobil-100 Net & Base Assembly
1 Base Bottom
2 Base Top
3 Ball Feed Gear Assembly
3a Ball Mixer Springs
3b Ball Feed Gear
3c Ball Feed Curved Wire
4 mobil-107 Ball Feed Motor
5 Front Support Assembly
5a Front Support Plate
5b Front Support Leg
5c Lower Ball Tube
5d Black Knob
6 Left Net Frame
7 Right Net Frame
8 Tensioning Arm
9 Ball Collection Tray
10 Ball Catching Net
10a Side Net Rubber Band
11–21 mobil-101 Robot Head Assembly
11 Upper Ball Tube
12 Robot Head Central
Support
13 mobil-106 Ball Throw Motor
14 mobil-110 Ball Throw Wheel
15 mobil-113 Ball Throw Motor Cover
ID # Part # Part Name
16 Directional Mounting
Plate
17 mobil-108 Trajectory Motor
17a Trajectory Gear
17b Trajectory Pin
17c Trajectory Pin Spring
18 mobil-109 Placement Motor
19 mobil-112 Deflector Plate
19a White Strip
19b Trajectory Pin Pad
20 Directional Motors Cover
21a Trajectory Motor Spacer
21b Placement Motor Screw
21c Trajectory Motor Screw
22 Power Circuit Board
23 Power Circuit Board
Cover
24 mobil-105 Tablet Cable
25 Control Panel Bracket
26 Prime Tablet
26a Tablet Holder
27 mobil-104 Power Supply (24V, 2.7A)
28 Power Supply AC Cord
29 UK Plug Adapter
29 US Plug Adapter
30 Tablet Power Supply
Additional replacement parts on demand!
