BWT Infinity A - Technical data

12
AUS
12 Technical data
Infinity A Model DN25 DN50
Connection size 1” BSP 2” BSP
Filter screen µm 90/110
Nominal pressure kPa 1600
Operating pressure range kPa 350-1600
Operating temperature (water) °C 5-30
Operating temperature (ambient) °C 5-40
Power supply V/Hz 240 / 50
Unit operation power V DC 24
Power consumption during backwashing W 8
Connection Module type Push and turn Four-hole flange
Overall length without fittings mm 100 125
Overall length with fittings mm 205 327
Total height A mm 510
Height B mm 315
Height C mm 295
Minimum distance pipe centre to floor D mm 670
Hose connection (diameter) mm 20
D
A
B
C
