These parts are currently available for purchase. Call C2Dx
®
Customer Service: 888-902-2239 for availability and
pricing.
Item Serial Number Description Quantity
1K 100822001 KIT: Upper front & Rear Housing. Includes both Front & Rear plastic
housing, Label, Membrane Panel (TP700 / TP700C)
1
2K 100898000 KIT: PC Board/Sensor Assembly - This assembly comes with a
precalibrated sensor and PCB assembly. They are a “Matched” set. Do
not use the old sensor with the new PC Board or the old PC Board with
the new sensor (TP700 / TP700C)
1
3K 100819001 KIT: Upper Rear Housing Assembly. Includes Rear Plastic Housing with
Label ( TP700 / TP700C )
1
4K 100818001 KIT: Upper Front Housing Assembly. Includes Front Plastic Housing
with Membrane Panel ( TP700 / TP700C )
1
5K 100821001 KIT: Heater Assembly. Includes Brass Manifold, 2 O-Rings, 4 Brass
Fittings. (TP700 / TP700C )
1
6K 100820000 KIT: Reservoir Assembly. Includes Reservoir, Gasket, Rubber Feet, Label. 1
1 03394000 Fitting, Manifold 2
2 03791001 Strap Assembly - Hose 1
3 04152000 Fan 1
5 08086000 Hose Assembly - Clik-Tite
®
Connectors 1
6 08648000 Hose Assembly - quick disconnects (colder) 1
7 Source Locally Tape, Teon, 1/4” Wide As required
8 Source Locally Ty-Wrap, Self Locking 5
9 81002028 Tubing, PVC, Panacea 1/4 ID x 3/8 OD x 3 1/2” LG 1
10 81002048 Tubing, PVC,Panacea 1/4 ID x 3/8 OD x 6” LG 1
11 90018029 Screw, Machine 4-40 x 1/2” FH Phillips 9
12 90018075 Screw Mach PH CR 8-32 UNC 2A x 3/8 LG S 4
13 90018082 Screw, Machine Pan HD #8-32 x 1 SST 1
14 90049005 LockWasher, Spring #6 SST 4
15 90076018 Bushing, Straight Thru (HEYCO #1210) 2
16 90295019 O-Ring 1
17 90295020 O-Ring, Silicone 4
18 90385000 Cup, Suction 3
19 90514003 Screw Type “BT” Thread Cutting Pan HD SST. #4 x 5/16” LG 4
20 90514013 Screw Type “BT” Thread Cutting Pan HD SST. #6 x 7/8” LG 4
21 90514020 Screw Type “BT” Thread Cutting #8 x 3/4” LG 1
22 91275059 Label Ground Identication 1
101176 Rev 1
