g. When needed, route the membrane ribbon (A) to the PCB Kit (B) from the Front Housing (C) (Figure 6 on page 28).
This prevents interference between the ribbon and moving components..
A
B
C
Figure 6: Ribbon cable
5. Verify proper operation before returning the product to service.
