Item Number Name Quantity
1K 100822001 KIT: Upper front & Rear Housing. Includes both Front & Rear
plastic housing, Label, Membrane Panel (TP700 / TP700C)
1
2K 100898000 KIT: PC Board/Sensor Assembly - This assembly comes with a
pre-calibrated sensor and PCB assembly. They are a match set.
Do not use the old sensor with the new PC Board or the old PC
Board with the new sensor ( TP700 / TP700C)
1
3K 100819001 KIT: Upper Rear Housing Assembly. Includes Rear Plastic
Housing with Label ( TP700 / TP700C )
1
4K 100818001 KIT: Upper Front Housing Assembly. Includes Front Plastic
Housing with Membrane Panel ( TP700 / TP700C )
1
5K 100821001 KIT: Heater Assembly. Includes Brass Manifold, 2 O-Rings, 4
Fittings. ( TP700 / TP700C )
1
6K 100820000 KIT: Reservoir Assembly. Includes Reservoir, Gasket, Rubber
Feet, Label.
1
1 03394000 Fitting, manifold 2
2 03791001 Strap assembly - hose 1
3 04152000 Fan 1
101176 Rev 1
T/Pump
®
Temperature Therapy Pump assembly
