CAB 5314 Series - Troubleshooting Error Messages; Applicator Error Messages

10 10
4 Error Messages
4.1 Error Messages of the Printer
For detailed information about printer errors (e.g. 'Paper out', 'Ribbon out', etc.)  Operator's manual of the printer
Error treatment :
 Clear the error results
 Press the feed key to synchronize the label feed, remove the peeled labels manually
 Press the pause key to quit the error state.
After error correction, the print of the label causing the error will be repeated.
4.2 Error messages of the Applicator
The following table contains an overview of error messages and their possible causes. It also suggests methods to
resolve the problem :
Error Message Possible Cause
Vac. plate empty
Label is removed from the waiting position on the pressure roll before the signal START
is coming in.
Upper position
Labelhasnotreachedtheareaofthereexsensorafter5secorwasnotdetected.
Table 2 Error messages of the applicator
Error treatment :
 Clear the error results
 Press the pause key to quit the error state.
i
Notice!
In fault check adjustments and settings with help of the Service Manual.
After error correction, the print of the label causing the error cannot be repeated without re-start of the print job.
Except at the error " Vac. plate empty" . In this case, the latest label will print again after quit the error with the
pause key and then press the Enter button
.
 Intheapplicationmode"Apply/Print"sendthesignal"Printrstlabel"orpressthebutton to send a printed
labeltothereexsensorpositionontheapplicator.
