8.3 Setting the Peel Position
To optimize the transfer of the labels from the printer to the applicator there two different parameters are available for
adjusting the peel position.
!
Attention!
 Firstadjusttheparameter"PeelPosition"intheprinterconguration.
 Following adjust the additional peel-off offset in the software.
It is very important to follow that procedure for a certain start after label loading and for the re-start after
error treatment.
Parameter"PeelPosition"intheprinterconguration
 Check the basic setting in the printer setup. Perform labelling cycles by alternately pressing the feed key and the
pre-dispense key „9.1 Test Mode without Print Job“.
 Adjust the "Peel Position" in such a way, that the blank labels are peeled-off completely from the liner
Peel-off offset in the software
 Check the setting in the software. Perform labelling cycles by repeatedly pressing the the pre-dispense key
„9.2 Test Mode with Print Job“
 Adjust the peel-off offset in such a way, that the printed labels are peeled-off completely from the liner
 Programming manual or software documentation.
8.4 Activation of Peel-off Mode
i
Notice!
 For labelling operation activate the peel-off mode in the software.
For direct programming use the P command  Programming manual.
