8 Diagnostic Functions
The Diagnostics menu contains several functions for troubleshooting
8.1 Printhead
The function Printhead provides an overview of important status information concerning the printhead on the display of
the printer.
Start menu.
Select Diagnostics > Printhead.
Return with Close.
The following parameters are displayed:
Line Meaning Example
1 Serial number of the printhead Serial no.
68-0252
2 Part number of the printhead Part no.
5977444
3 Firmware revision of the printhead Firmware
2.1.0
4 Temperature of the printhead Temperature
26.2 °C
5 Resolution of the printhead Resolution
12 DPMM (dots/millimeter)
6 Print width / Number of dots Width/no. of dots
106mm/1248
7 Operative time/Number of printed labels
with the current printhead
Hours/no. of labels
424h/32018
8 Previously printed paper lengths with thermal direct printing / thermal
transfer printing
Thermal/Transfer
29.04m/286.42m
9 Previously printed paper length with heat level < 0 Heat level <0
44.31m
10 Previously printed paper length with heat level 0 - 7 Heat level 0-7
219.93m
11 Previously printed paper length with heat level 8 - 14 Heat level 8-14
50.41m
12 Previously printed paper length with heat level > 14 Heat level >14
0.81m
13 Resistance of the printhead Resistance
1110Ω
14 Description of the printhead Description
4"/300dpi/Kyocera
Table 24 Printhead display
