CAB Hermes+ User Manual

26 26
8.2 Device Dimensions
Fig. 19 Device dimensions
Dim. Designation Dim. in mm
Hermes+ 2 Hermes+ 4 Hermes+ 4.3 Hermes+ 6
L R L R L R L R
I Distance printhead - peel-off edge 15
J Distance 1st heating point - material edge
203 dpi
300 dpi
600 dpi
-
1,0
1,0
-
3,7
1,0
1,0
1,0
1,0
2,8
1,0
1,1
1,0
1,0
-
2,7
-1,7
-
-0,6
2,1
-
-0,6
2,1
-
K Print width
203 dpi
300 dpi
600 dpi
-
54,2
57,0
-
54,2
57,0
104,0
105,6
105,6
104,0
105,6
105,6
104,0
108,4
-
104,0
106,7
-
167,4
162,6
-
167,4
162,6
-
SX Distance gap/reective sensor -
material edge
i.e. permissible distance of reex or cut-out
marks to the material edge
2 - 26 2 - 47
SY Distance gap/reective sensor -
printhead
65
Table 9 Device dimensions
8 Labels

CAB Hermes+ Specifications

General

Power Supply	100 - 240 V AC, 50/60 Hz
Print Technology	Thermal Transfer
Resolution	203 dpi
Interfaces	USB, Ethernet
Display	LCD
Memory	8 MB RAM
Supported Barcodes	1D and 2D barcodes
