26 — electricalc
®
Pro
Ohm’S laW
The ElectriCalc Pro’s built-in Ohm’s Law functions allow you to easily
solve for Voltage (Volts), Current (Amps), or Resistance (Ohms) by
entering in any two variables (e.g, Volts and Amps) and solving for
the third (e.g., Ohms).
Ohm’s Law: V = I x R
The Ohm’s Law functions on the ElectriCalc Pro are
identied as follows:
• Vdc = Voltage, in Volts
• Idc = Current, in Amps
• R = Resistance, in Ohms
Finding Volts
The Current in a circuit is 0.0125 Amps, and the total Resistance is
480 Ohms. Find the Voltage.
KEYSTROKE DISPLAY
 0.
1. Enter Current:
 (Idc) Idc 0.0125 A
2. Enter Resistance:
 (R) OHMS 480.
3. Find Voltage:
  (Vdc) Vdc 6. V
Finding Amps
A 120k electrical resistor is plugged into a 12 volt circuit. Find the
Current (in Amps).
KEYSTROKE DISPLAY
 0.
1. Enter Resistance:
 (R) KOHM 120.

Calculated Industries ElectriCalc Pro Specifications

General

Type	Scientific
Cover	Yes
Form factor	Pocket
Control type	Buttons
Product color	Yellow
Digits	8 digits
Display type	LCD
Display tilting	No
Display size (HxV)	15.88 x 63.5 mm
Display number of lines	- lines
Display size (HxV) (imperial)	0.625 x 2.5 \
Storage media type	-
Battery type	CR2016
Power source	Battery
Battery voltage	3 V
Number of batteries supported	1

Weight and Dimensions

Depth	16 mm
Width	76 mm
Height	142 mm
Weight	127.5 g
