User's GUide — 51
5. Find Conduit Size:
IMC 1.25 in COND SIZE
* Wire Size can also be entered in Circular Mils (e.g.,
enters 26,420 CMILs and displays 6 AWG
Wire Size).
Finding Number of Wires in Existing Conduit —
Same Size, Various Types
Find the maximum number of #10 THHN Copper wires that can be
pulled through an existing 3 inch EMT Conduit. How many XHHW
wires? How many THW wires?
KEYSTROKE DISPLAY
0.
1. Set to Copper (if necessary):
(
Cu/Al
)
Cu 0.
2. Enter Conduit Type:
(
Cond Type
)
EMT nonE COND
3. Enter Wire Size:
*
AWG 10 CU WIRE SIZE
4. Enter Conduit Size:
EMT 3.00 in COND SIZE
5. Find maximum THHN #:
THHN 167. TTL WIRES
6. Find maximum XHHW #:
XHHW 145. TTL WIRES
7. Find maximum THW #:
THW 145. TTL WIRES
* Wire Size can also be entered in Circular Mils (e.g.,
enters 10,380 CMILs and displays 10 AWG
Wire Size).
KEYSTROKE DISPLAY
