Calculated Industries ElectriCalc Pro User Manual

User's GUide — 29
(cont’d)
KEYSTROKE DISPLAY
5. Enter HP:
 IND* 10. HP
* If IND is not shown, press   until IND is displayed in the upper left
area of the display.
6. Find Full-Load Current:
 FLC 28. A
7. Find 125% Ampacity Wire Size:
(125%) AWG 8 CU WIRE SIZE 125%
8. Find max Ampacity:
 8* 40.0 WIRE A125%
* The Wire Size will be shown in the upper left area of the display when
displaying the Wire Ampacity rating.
Finding Synchronous Motor Horsepower
A Synchronous motor is dened as having a 27 Amp load on a 240
Volt, 3Ø circuit. What is its Horsepower?
KEYSTROKE DISPLAY
 0.
1. Set to 3-Phase:
(3Ø) 3Ø 3 PH
2. Set to Synchronous motor:
*(Ind/Sync/DC) SYNC 0.
* If necessary, continue pressing   until the desired Motor Type
is displayed.
3. Enter Volts:
 VOLT 240.
4. Enter Amps:
 AMPS 27.

Calculated Industries ElectriCalc Pro Specifications

General

Type	Scientific
Cover	Yes
Form factor	Pocket
Control type	Buttons
Product color	Yellow
Digits	8 digits
Display type	LCD
Display tilting	No
Display size (HxV)	15.88 x 63.5 mm
Display number of lines	- lines
Display size (HxV) (imperial)	0.625 x 2.5 \
Storage media type	-
Battery type	CR2016
Power source	Battery
Battery voltage	3 V
Number of batteries supported	1

Weight and Dimensions

Depth	16 mm
Width	76 mm
Height	142 mm
Weight	127.5 g
