Connection

/*.
.


How to prepare the cables for connecting the plug connectors.

1.*0

Cable for 4-pole and 6-pole plug connector
Circuit Wire cross-section
12 Volt consumer 1 1.50 mm² min.
12 Volt consumer 2 1.50 mm² min.
12 Volt consumer 3 1.50 mm² min.
Continuous current (heat-
ing/immediate light)
1.50 mm² min.
Water pump 1.50 mm² min.
Refrigerator 2.50 mm²
Cable for 12-pole plug connector
Circuit Wire cross-section
Charging current cable, battery 2 4.00 mm²
Measuring cable D+ 0.75 mm²
Measuring cable B+ (batt. 2) 0.75 mm²
Positive cable, battery 2 6.00 mm²
Negative cable, battery 2 4.00 mm²
Positive cable, battery 1 6.00 mm²
