Calorex Pro-Pac PPT45EHC - Page 38

1760
1810
446
837
SERVICE
PANEL
Pro-Pac 70
DIMENSIONS IN mm
ISSUE 1
ALLOW 500mm FOR ACCESS TO SERVICE PANELS
WATER CONNECTIONS 1½" BSPM CONDENSATE 1½" BSPM
WATER
OUT
WATER
IN
SERVICE PANEL
NOMINAL FAN
DIAMETER 815
AIR IN
AIR OUT
SERVICE
PANEL
SERVICE PANEL
ELECTRIC BOX
ACCESS
CONSOLE
HP
SWITCH
LP
SWITCH
CHILL
LIMIT
SWITCH
MAINS
IN
302.50
65
1190
SERVICE
PANEL
1310
569.50
SERVICE PANEL
866
CONDENSATE OUT
POSITION IN BASE
936
CONDENSATE OUT
POSITION IN BASE
U
P
10
RED
AMBER
RED
AMBER
RED
GREEN
GREEN
CLEAR
*1110
*FIXING CENTRES TO SECURE MACHINE
*1000
38
SD566250 ISSUE 35
PR0-PAC SYSTEM OWNER INSTALLATION MANUAL
