Pro-Pac 140
DIMENSIONS IN mm
ISSUE 1
LEAVE 500mm CLEARANCE FOR SERVICE PANELS
WATER CONNECTIONS 2" BSPM CONDENSATE 1½" BSPM
SERVICE PANEL
SERVICE PANEL
SERVICE PANEL
NOMINAL FAN
DIAMETER 815
821
514.50
1437.50
CHILL LIMIT
SWITCH
SERVICE PANEL
ELECTRIC BOX
ACCESS
1650
SERVICE PANEL
MAINS
HP SWITCH
LP SWITCH
CHILL LIMIT
SWITCH
CONSOLE
HP SWITCH
LP SWITCH
U P
21
10
AMBER
RED
RED
AMBER
AMBER AMBER
CLEAR
GREEN
GREEN
RED
2146
2210
*1616
1290
CONDENSATE OUT
POSITION IN BASE
WATER
OUT
WATER
IN
AIR ON
AIR OFF
SERVICE
PANEL
647
324
592
1340
AIR ON
1396
CONDENSATE OUT
POSITION IN BASE
*1562
*FIXING CENTRES FOR SECURING MACHINE
254254
CONDENSATE OUT
POSITIONS IN BASE
FAN 1
FAN 2
43
SD566250 ISSUE 35
