86 ARGO Digital Broadcast IP Production Console
Specifications
SYNCHRONISATION INPUTS
AUDIO PERFORMANCE DATA
ANALOGUE OUTPUT SPECS (FIXED FORMAT & MODULAR I/O)
Digital - Analogue
Conversion
24 Bit
Output Balance
Electronically balanced. 20Hz to 20kHz, better than -35dB, typically -45dB
Output Impedance
<40 Ohms
Distortion
-1dBFS @ 1kHz — Better than 0.006%
-20dBFS @ 1kHz — Better than 0.003%
-60dBFS @ 1kHz — Better than 0.3%
Frequency Response
20Hz to 20kHz +/- 0.25dB
Notes
Analogue output for 0dBFS matches input setting into >1kOhms (+24dBu max into 600 Ohms)
Digital to Digital
(AES3) Distortion
-1dBFS, 20Hz to 10kHz — Better than 0.0001%
Digital to Digital
(AES3 with SRC) Distortion
-1dBFS, 20Hz to 10kHz — Better than 0.0002%
Frequency Response
(Analogue Input to Output)
20Hz to 20kHz +/- 0.5dB
48KHz Synchronisation
PTPv2 Grand Master Clock
TTL Wordclock (48kHz)
Video
Internal Crystal Reference
LATENCY @ 48KHZ SAMPLE RATE *
From To Via Samples @48kHz
AES3 inputs (SRC off)
AES3 Outputs Port to port TBC TBC
AES3 Outputs Channel, group, and aux, track or main output TBC TBC
Analogue Outputs Port to port TBC TBC
Analogue Outputs Channel, group, and aux, track or main output TBC TBC
Turning SRC on adds to the above: + 39 + 0.813ms
Mic/Line inputs
AES3 Outputs Port to port TBC TBC
AES3 Outputs Channel, group, and aux, track or main output TBC TBC
Analogue Outputs Port to port TBC TBC
Analogue Outputs Channel, group, and aux, track or main output TBC TBC
* Note: These latency figures are not yet available.
