Analogue INPUTS
system set for
to Digital Outputs with 0 dB gain
+18 dBu = 0 dBFS 110 d B
+24 dBu = 0 dBFS 116 d B
to Analogue Outputs with 0 dB gain *
N/A 118 d B
DYNAMIC RANGE FOR ANALOGUE AND AES3 (INPUTS)
AES3 UNBALANCED DIGITAL INPUTS
system set for SRC on I/P SRC on I/P
to Digital Outputs with 0 dB gain
N/A off 138 dB on 130 dB
to Analogue Outputs with 0 dB gain
+18 dBu = 0 dBFS off 111 d B on 111 d B
+24 dBu = 0 dBFS off 117 d B on 117 d B
AES3 BALANCED DIGITAL INPUTS
(MODULAR I/O ONLY)
system set for SRC on I/P SRC on I/P
to Digital Outputs with 0 dB gain
N/A off 138 dB on 130 dB
to Analogue Outputs with 0 dB gain
+18 dBu = 0 dBFS off 111 d B on 111 dB
+24 dBu = 0 dBFS off 117 d B on 117 d B
Analogue OUTPUTS
system set for SRC on I/P SRC on I/P
from Digital Inputs with 0 dB gain
+18 dBu = 0 dBFS off 111 dB on 111 d B
+24 dBu = 0 dBFS off 117 d B on 117 dB
from Analogue Inputs with 0 dB gain *
N/A N/A 118 dB
DYNAMIC RANGE FOR ANALOGUE AND AES3 (OUTPUTS)
AES3 UNBALANCED DIGITAL
OUTPUTS
system set for SRC on I/P SRC on I/P
from Digital Inputs with 0 dB gain
N/A off 138 dB on 130 dB
from Analogue Inputs with 0 dB gain
+18 dBu = 0 dBFS N/A 110 d B N/A
+24 dBu = 0 dBFS N/A 116 d B N/A
AES3 BALANCED DIGITAL OUTPUTS
(MODULAR I/O ONLY)
system set for SRC on I/P SRC on I/P
from Digital Inputs with 0 dB gain
N/A off 138 dB on 130 dB
from Analogue Inputs with 0 dB gain
+18 dBu = 0 dBFS N/A 110 d B N/A
+24 dBu = 0 dBFS N/A 116 d B N/A
* The analogue to analogue dynamic range is achieved because the system can accept analogue signals of up to +28 dBu from input
to output at 0 dB gain. Obviously, an analogue input of up to +28 dBu must be attenuated to output this digitally, but this attenuation
will maintain the Dynamic Range of the input, as the analogue input noise will be attenuated by the same amount as the signal, and
the analogue input noise will still be dominant above the noise floor of the digital system.
