88 ARGO Digital Broadcast IP Production Console
Specifications
ANALOGUE INPUT SPECS (ON TYPE R - UR6500, AD6501 AND AD6502)
AES3 BALANCED DIGITAL INPUTS (ON TYPE R - UR6500, AD6501 AND JD6503) & (ON ARGO - JB6569)
AES3 BALANCED DIGITAL OUTPUTS (ON TYPE R - UR6500, AD6501 AND JD6503) & (ON ARGO - JB6569)
Format
AES/EBU (AES3) 24-bit.
Interface, Input Sensitivity
110 Ohm balanced (D-Type), 0.2V-7.0V Pk-Pk
Sample Rate Conversion
24-Bit switchable on all AES inputs, SRC Range 30kHz-100kHz
SRC THD+N
-117dB @ 1kHz, 0.00014%
Format
AES/EBU (AES3) 24-bit
Interface
110 Ohm balanced (D-Type)
Jitter
<0.015UI (2.5ns) peak
Analogue - Digital
Conversion
24 Bit
Input
Electronically Balanced
Input Impedance
5.4k Ohms at mic/line level gain settings
Sensitivity
+18 / -78dB for Mic/Line Inputs
Maximum Input Level
24dBu
Frequency Response
20Hz to 20kHz +/- 0.25dB on Mic/Line Inputs
Distortion
-1dBFS @ 1kHz - Better than 0.005% (-86dB)
-20dBFS @ 1kHz - Better than 0.003% (-90dB)
-40dBFS @ 1kHz - Better than 0.03% (-70dB)
Dynamic Range(CCIR-RMS)
-116 d B
Idle Channel Noise
-116dBFS (88dBu)
Equivalent Input Noise
-126dB (150 Ohm source)
Input CMR
(Common Mode Rejection)
>90dB at a 52dB gain setting
>75dB at a 4dB gain setting
Crosstalk
-115dB or better on adjacent inputs with 0dBFS tone at 1kHz on Source
Phantom power current limit
9.5mA / channel
ANALOGUE OUTPUT SPECS (ON TYPE R - UR6500, AD6501 AND AD6502)
Digital - Analogue
Conversion
24 Bit
Output Balance
Electronically Balanced
Output Impedance
31 Ohms
Maximum Output Level
24dBu
Frequency Response
20Hz to 20kHz +/- 0.25dB
Distortion
-1dBFS @ 1kHz - Better than 0.002%(-93dB)
-20dBFS @ 1kHz - Better than 0.003% (-90dB)
-40dBFS @ 1kHz - Better than 0.03% (-70dB)
Dynamic Range (CCIR-RMS)
-113 dB
Idle Channel Noise
-113dBFS (85dBu)
Crosstalk
-105dB or better on adjacent outputs with 0dBFS tone at 1kHz on Source
