5.8 Releasing the gearmotor
5.9 Micro-switch settings
To release the gearmotor, used the lever located above the rod.
RELEASE
LOCKING
Micro-switch
Micro-switch
Upper cam
Lower cam
Lower cam fastening
screw
Upper cam fastening
screw
LIMIT-SWITCH ASSEMBLY
If the system already has mechanical stops, do not lock the cams, otherwise calibrate them in the following way:
