CAME FA40230CB

FA40230FA40230CB
U V W X Y E
+ ENC1 - + ENC2 -
FA40230CB
U V W X Y E
+ ENC1 - + ENC2 -
FA40230FA40230CB
U V W X Y E
+ ENC1 - + ENC2 -
U V W X Y E
+ ENC1 - + ENC2 -
FA40230CBFA40230
FA40230CBFA40230
Page 17 - Manual code:
119DW02EN
vers. 3 03/2014 © CAME Cancelli Automatici S.p.A. - The data and information provided in this manual are subject to change at any time without prior notice by CAME Cancelli Automatici S.p.A.
Electrical connections:
operator installed on the right (internal view).
Electrical connections:
operator installed on the left (internal view).
(Default confi guration)
Encoder wire colour:
+ = W
hite
ENC = Brown
- = Green
Electrical connections:
oper
ator installed on the left and gearmotor installed on the
right (internal view) with oper
ator with delayed closing.
(Default confi guration)
Electrical connections:
gearmotor installed on the left and operator installed
on the right (internal view) with operator with delayed
closing.
Encoder wire colour:
+ = W
hite
ENC = Brown
- = Green
Connection between the gearmotor with encoder and the second gearmotor
Connecting the gearmotor with encoder
