CAME FA40230CB User Manual

3
8
4
7
6
5
2
11
10
1
9
200
235
230
173
100
81,5
40
120
60
18
Page 4 - Manual code: 119DW02EN vers. 3 03/2014 © CAME Cancelli Automatici S.p.A. - The data and information provided in this manual are subject to change at any time without prior notice by CAME Cancelli Automatici S.p.A.
Dimensions (mm)
Description of the components
1. Cover
2. Gearmotor
3. Control board
4. Pillar bracket
5. Transmission arm
6. Driven arm
7. Gate bracket
8. Unlocking hatch
9. Mechanical end stops
10. LED control board
11. Straight arm with 001STYLO-BD slide rail
(optional accessory)
