Page 23 - Manual code:
119DW02EN
vers. 3 03/2014 © CAME Cancelli Automatici S.p.A. - The data and information provided in this manual are subject to change at any time without prior notice by CAME Cancelli Automatici S.p.A.
F23 Opening delayed time0 = Disabled (default) / 1 = 1 s / 2 = 2 s / … / 10 = 10 s
After an opening command, the M1 gearmotor starts with a delay. The delay time can be set between 1 s and 10 s.
F24 Closing delay time 0 = Disabled (default) / 1 = 1 s / 2 = 2 s / … / 25 = 25 s
After a closing command or after automatic closing, the M2 gearmotor starts with a delay. The delay time can be set between 1 s and 25 s.
F30 Slowdown speed 0 = Disabled / 1 = maximum speed; / 2 = Vintermediate speed (default) / 3 = minimum speed.
Setting the gearmotor speed during slowdown.
F33 Calibration speed30 = Minimum speed / … / 50 = Speed (default) / … / 60 = Maximum speed
Setting the speed of the run during calibration.
F34 Run sensitivity 10 = maximum sensitivity / … / 100 = minimum sensitivity (default)
Adjusting the sensitivity of obstacle detection during the run.
F35 Slowdown sensitivity 10 = maximum sensitivity / … / 100 = minimum sensitivity (default)
Adjusting the sensitivity of obstacle detection during slowdown.
F36 Partial opening adjustment 10 = 10% of the run (default) / … / 80 = 80% of the run
Adjustment in percentage of the total run, from leaf opening of the M2 gearmotor.
F37 Opening slowdown point 10 = 10% of the run / … / 25 = 25% of the run (default) / … / 60 = 60% of the run
Adjustment in percentage of the total run, from the starting point of slowdown during opening.
F38 Closing slowdown point 10 = 10% of the run / … / 25 = 25% of the run (default) / … / 60 = 60% of the run
Adjustment in percentage of the total run, from the starting point of slowdown during closing.
F39 Opening approach point 1 = 1% of the run / … / 5 = 5% of the run (default) / … / 10 = 10% of the run
Adjustment in percentage of the total run, from the starting point of approach during opening.
F40 Closing approach point 1 = 1% of the run / … / 5 = 5% of the run (default) / … / 10 = 10% of the run
Adjustment in percentage of the total run, from the starting point of approach during closing.
F46 Number of motors 0 = M1 and M2 (default) / 1 = M2
Setting the number of gearmotors connected to the control panel.
F50 Data saving0 = Disabled (default) / 1 = Activated
Saving the users and memorised settings in the memory roll.
N.B. this function appears only if a memory roll has been inserted in the control board.
F51 Data reading0 = Disabled (default) / 1 = Enabled
Loading the data saved into the memory roll.
N.B. this function appears only if a memory roll has been inserted in the control board.
F59 Enabling CAME logo0 = Disabled / 1 = Enabled (default) / 10 = 10 s / … / 180 = 180 s
The CAME can remain always on (default), always o , or can come on after the gate has closed for a time that can be set between 10 s and 180 s.
U1 Adding a user1 = Step-by-step command (open-close) / 2 = Sequential command (open-stop-close-stop) / 3 = Open only command
4 = Pedestrian/partial command
Entry of up to 25 users and association of each with a function chosen from those available. Entry must be done with the transmitter or other command
device (see user paragraph with associated command).
U2 Deleting a user
Deleting a single user.
U3 Deleting a user0 = Disabled / 1 = Deleting all users
Deleting all users.
User menu
Info menu
H 1 Version
Shows the software version.
