TROUBLESHOOTING
PROBLEM REFERENCE CHECK
The barrier neither opens nor closes 1-2-3-4-6-8-18 1 - Lock the inspection hatch with the key
The boom opens but does not close 4-7-10 2 - Deactivate the MAINTAINED ACTION function
The boom closes but does not open 4-7-9 3 - Check the power supply and fuses
Thebarrier does not automatically close 11-12-13 4 - The NC contacts are open
The barrier does not work with the transmitter 2-14-16 6 - Deactivate the MASTER-SLAVE function
The boom's direction of travel is inverted 7-18 7 - Check the boom's balancing and spring tautness
Only one transmitter works 22 8 - Deactivate the OBSTRUCTION DETECTION function
The photocells do not work 12-23-24 9 - Check the opening endstop
The warning LED flashes quickly 4 10 - Check the closing endstop
The warning LED stays lit 13 11 - Activate the AUTOMATIC CLOSING function
The boom does not reach the endstop 7 12 - Check the proper direction of travel
The boom cannot be balanced 7-15 13 - Check the control devices
The barrier does not slow down 7-15 14 - Replace the AF card
The barrier does not work with emergency
batteries
8-25-26 15 - Check the length ration between boom and applied acces-
sories
The boom starts slow 7 16 - Memorize the radio code again
18 - Adjust the sensitivity
22 - Enter or duplicate the same code on all transmitters
23 - Activate the photocells
24 - Connect the photocells serially instead of in parallel fashion
25 - Check the batteries
26 - Respect the photocell's power supply polarities

CAME GARD 8 SERIES Specifications

General

Model	GARD 8 SERIES
Type	Automatic Barrier
Motor voltage	24 V DC
Power	300 W
Operating temperature	-20°C to +55°C
Protection rating	IP54
Input Voltage	230 V AC
Output Voltage	24 V DC
Protection Degree	IP54
Power supply	230 V AC
Opening time	4 to 8 seconds
