CAME PB1100 Installation Manual

p.
3
3 - Manual code:
119PM75
119PM75 v.
4
4 10/2014 © CAME S.p.A. - The data and information in this manual may be changed at any time and without notice.
ENGLISH
DESCRIPTION
Operator for one swing-leaf, with 24 V DC reversible gearmotor and built-in control panel.
LEGEND
 This symbol shows which parts to read carefully.
⚠
This symbol shows which parts describe safety issues
☞
This symbol shows which parts to tell users about.
Limits to use
Memory PB1100
Max. gate leaf length (m) 1.2 1 0.8
Maximum gate-leaf weight (kg) 150 200 250
REFERENCE REGULATIONS
CAME S.p.A. is certified for the: ISO 9001 quality and ISO 14001 environmental management systems.
This product complies with the current regulations mentioned in the declaration of conformity.
Intended use
This operator is designed to power swing doors for intensive duty.
Any installation and/or use other than that specified in this manual is forbidden.
Technical data
Memory PB1100
Power supply (V - 50/60 Hz) 230 AC
Motor power supply (V) 24 DC
Control panel draw (mA) 70
Motor absorption (mA) 600
Power (W) 138
Maneuvering time 90° (s) 2 ÷ 5
Duty cycle (%) intensive duty
Torque (Nm) 40
Working temperature (°C) -20 ÷ +55
