ENGLISH
Articulated arm PB1002, for push-to-open doors
For details on drilling and fastening the base, see the literature about the arm.
Sliding arm PB1001, for pull-to-open doors
For details on drilling and fastening the base, see the literature about the arm.
up to 120°
up to 180°
