CAME SDN8 User Manual

p.
19
19 - Manual code
FA 00 014- EN
FA00014-EN v.
3
3
04/2016 - © Came S.p.A. The contents of this manual may be changed at any time without prior notice.
F1 Total stop [1-2] 0 = Deactivated (default) / 1 = Activated
NC input – Gate stop that excludes any automatic closing; to resume movement, use the control device. The
safety device is inserted into [1-2].
F2 Input [2-CX] 0 = Deactivated (default) / 1 = C1 / 2 = C2 / 3 = C3 / 4 = C4 / 7 = C7
/ 8 = C8
NC input – Can associate: C1 = reopening during closing by photocells, C2 = reclosing during opening by
photocells, C3 = partial stop, C4 = obstruction wait, C7 = reopening during closing by sensitive safety-edges,
C8 = reclosing during opening by sensitive safety-edges.
F3 Input [2-CY] 0 = Deactivated (default) / 1 = C1 / 2 = C2 / 3 = C3 / 4 = C4 / 7 = C7
/ 8 = C8
NC input – Can associate: C1 = reopening during closing by photocells, C2 = reclosing during opening by
photocells, C3 = partial stop, C4 = obstruction wait, C7 = reopening during closing by sensitive safety-edges,
C8 = reclosing during opening by sensitive safety-edges.
F5 Safety test 0 = Deactivated (default) / 1 = CX / 2 = CY / 4 = CX+CY
After every opening or closing command, the board will check whether the photocells are working properly.
 The safety test is always active for wireless devices.
F6 Maintained action 0 = Deactivated (default) / 1 = Activated
The gate opens and closes by keeping the button pressed. Opening button on contact 2-3P and closing button
on contact 2-7. All other control devices, even radio-based ones, are excluded.
F7 Command [2-7] 0 = Step-step (default) / 1 = Sequential
From the control device connected to 2-7 it performs the step-step (open-close-invert) or sequential (open-stop-
close-stop) command.
F8 Command [2-3P] 0 = Opening (default) / 1 = Partial opening
From the control device connected to 2-3P it performs the total opening (0) or partial opening (1) of the gate.
 The partial opening time is adjusted on function F 71.
F9 Obstruction detection with
motor idle
0 = Deactivated (default) / 1 = Activated
With the gate closed, opened or totally stopped, the gearmotor stays idle if the safety devices, that is, photocells
or sensitive safety-edges detect an obstruction.
F10 Gate-.open signal output 0 = lit when gate is open or moving (default) /
1 = when opening it fl ashes intermittently every half-second,
when closing it fl ashes intermittently every second,
stays lit when gate is open
is o when gate is closed
It signals the gate status. The signal device is connected to contact 10-5.
F11 Encoder 0 = Activated (default) / 1 = Deactivated
Functions menu
 IMPORTANT! Start programming by fi rst performing the following: MOTOR-TYPE SETTING (A1), OPENING
DIRECTION (F54), TOTAL STOP (F1) and TRAVEL CALIBRATION (A3)
⚠
Programming the features is to be done when the operator is stopped.
 You can memorize up to 25 users.
