CAME SDN8 User Manual

290
145 145
300
170
363
212
160
106
117
250
85 85
p.
4
4 - Manual code
FA 00 014- EN
FA00014-EN v.
3
3 04/2016 - © Came S.p.A. The contents of this manual may be changed at any time without prior notice.
LEGEND
This symbol shows which parts to read carefully.
⚠
This symbol shows which parts describe safety issues
☞
This symbol shows which parts to tell users about.
REFERENCE REGULATIONS
Came S.p.A. is certifi ed for the: ISO 9001 quality and ISO 14001 environmental management systems..
This product complies with the current regulations mentioned in the declaration of conformity.
DESCRIPTION
Operator complete with control board, movement control and obstruction detection device and mechanical limit
switches for sliding gates weighing up 1,000 Kg and measuring 20 m in length.
Intended use
The operator is designed to power sliding gates in residential and apartment block settings.
 Any installation and/or use other than that specifi ed in this manual is forbidden.
Limits to use
Type
SDN4 SDN6 SDN8 SDN10
Max. gate leaf length (m) 14 18 20 20
Maximum gate-leaf weight (kg) 400 600 800 1000
Pinion module 4 4 4 4
Dimensions (mm)

CAME SDN8 Specifications
