3 04/2016 - © Came S.p.A. The contents of this manual may be changed at any time without prior notice.
WARNING!
Important safety instructions for people:
READ CAREFULLY!
FOREWORD
• THIS PRODUCT MUST ONLY BE USED FOR ITS INTENDED
PURPOSE. ANY OTHER USE IS DANGEROUS. CAME S.P.A.
I
S NOT LIABLE FOR ANY DAMAGE CAUSED BY IMPROPER,
WRONGFUL AND UNREASONABLE USE • KEEP THESE
WARNINGS TOGETHER WITH THE INSTALLATION AND
OPERATION MANUALS THAT COME WITH THE GEARMOTOR.
B
EFORE INSTALLING
(CHECKING WHAT'S THERE: IF YOUR EVALUATION IS NEGATIVE,
DO NOT PROCEED BEFORE HAVING COMPLIED WITH ALL
SAFETY REQUIREMENTS)
• C
HECK THAT THE AUTOMATED PARTS ARE IN GOOD
MECHANICAL ORDER, THAT THE GEARMOTOR IS LEVEL AND
ALIGNED, AND THAT IT OPENS AND CLOSES PROPERLY.
M
AKE SURE YOU HAVE SUITABLE MECHANICAL STOPS •
IF THE GEARMOTOR IS TO BE INSTALLED AT A HEIGHT OF
OVER 2.5 M FROM THE GROUND OR OTHER ACCESS LEVEL,
MAKE SURE YOU HAVE ANY NECESSARY PROTECTIONS AND/
OR WARNINGS IN PLACE • IF ANY PEDESTRIAN OPENINGS
ARE FITTED INTO THE GEARMOTOR, THERE MUST ALSO BE A
A SYSTEM TO BLOCK THEIR OPENING WHILE THEY ARE MOVING
•
MAKE SURE THAT THE OPENING AUTOMATED DOOR OR
GATE CANNOT ENTRAP PEOPLE AGAINST THE FIXED PARTS
OF THE GEARMOTOR • DO NOT INSTALL THE GEARMOTOR
UPSIDE DOWN OR ONTO ELEMENTS THAT COULD YIELD AND
BEND. IF NECESSARY, ADD SUITABLE REINFORCEMENTS TO
THE ANCHORING POINTS • DO NOT INSTALL DOOR OR GATE
LEAVES ON TILTED SURFACES • MAKE SURE ANY SPRINKLER
SYSTEMS CANNOT WET THE GEARMOTOR FROM THE GROUND
UP • MAKE SURE THE TEMPERATURE RANGE SHOWN ON
THE PRODUCT LITERATURE IS SUITABLE TO THE CLIMATE
WHERE IT WILL BE INSTALLED • FOLLOW ALL INSTRUCTIONS
AS IMPROPER INSTALLATION MAY RESULT IN SERIOUS BODILY
INJURY • IT IS IMPORTANT TO FOLLOW THESE INSTRUCTIONS
FOR THE SAFETY OF PEOPLE. KEEP THESE INSTRUCTIONS.
I
NSTALLING
• SUITABLY SECTION OFF AND DEMARCATE THE ENTIRE
INSTALLATION SITE TO PREVENT UNAUTHORIZED PERSONS
FROM ENTERING THE AREA, ESPECIALLY MINORS AND
CHILDREN • BE CAREFUL WHEN HANDLING GEARMOTORS
THAT WEIGH OVER 20 KG. IF NEED BE, USE PROPER SAFETY
HOISTING EQUIPMENT • ALL OPENING COMMANDS (THAT
IS, BUTTONS, KEY SWITCHES, MAGNETIC READERS, AND
SO ON) MUST BE INSTALLED AT LEAST 1.85 M FROM
THE PERIMETER OF THE GATE'S WORKING AREA, OR WHERE
THEY CANNOT BE REACHED FROM OUTSIDE THE GATE. ALSO,
ANY DIRECT COMMANDS (BUTTONS, TOUCH PANELS, AND
SO ON) MUST BE INSTALLED AT LEAST 1.5 M FROM THE
GROUND AND MUST NOT BE REACHABLE BY UNAUTHORIZED
PERSONS • ALL MAINTAINED ACTION COMMANDS, MUST BE
FITTED IN PLACES FROM WHICH THE MOVING GATE LEAVES
AND TRANSIT AND DRIVING AREAS ARE VISIBLE • APPLY, IF
MISSING, A PERMANENT SIGN SHOWING THE POSITION OF THE
RELEASE DEVICE • BEFORE DELIVERING TO THE USERS, MAKE
SURE THE SYSTEM IS EN 12453 STANDARD COMPLIANT
(
REGARDING IMPACT FORCES), AND ALSO MAKE SURE THE
SYSTEM HAS BEEN PROPERLY ADJUSTED AND THAT ANY
SAFETY, PROTECTION AND MANUAL RELEASE DEVICES ARE
WORKING PROPERLY • APPLY WARNING SIGNS (SUCH AS THE
GATE'S PLATE) WHERE NECESSARY AND IN A VISIBLE PLACE
S
PECIAL USER-INSTRUCTIONS AND RECOMMENDATIONS
• K
EEP GATE OPERATION AREAS CLEAN AND FREE OF
ANY OBSTRUCTIONS. MAKE SURE THAT THE PHOTOCELLS
ARE FREE OF ANY OVERGROWN VEGETATION AND THAT
THE GEARMOTOR'S AREA OF OPERATION IS FREE OF ANY
OBSTRUCTIONS • DO NOT ALLOW CHILDREN TO PLAY WITH
FIXED COMMANDS, OR TO LOITER IN THE GATE'S MANEUVERING
AREA. KEEP ANY REMOTE CONTROL TRANSMITTERS OR
ANY OTHER COMMAND DEVICE AWAY FROM CHILDREN,
TO PREVENT THE GEARMOTOR FROM BEING ACCIDENTALLY
ACTIVATED. • THE APPARATUS MAY BE USED BY CHILDREN
OF EIGHT YEARS AND ABOVE AND BY PHYSICALLY, MENTALLY
AND SENSORIALLY CHALLENGED PEOPLE, OR EVEN ONES
WITHOUT ANY EXPERIENCE, PROVIDED THIS HAPPENS UNDER
CLOSE SUPERVISION OR ONCE THEY HAVE BEEN PROPERLY
INSTRUCTED TO USE THE APPARATUS SAFELY AND ABOUT
THE POTENTIAL HAZARDS INVOLVED. CHILDREN MUST NOT
PLAY WITH THE APPARATUS. CLEANING AND MAINTENANCE
BY USERS MUST NOT BE DONE BY CHILDREN, UNLESS
PROPERLY SUPERVISED • FREQUENTLY CHECK THE SYSTEM
FOR ANY MALFUNCTIONS OR SIGNS OF WEAR AND TEAR OR
DAMAGE TO THE MOVING STRUCTURES, TO THE COMPONENT
PARTS, ALL ANCHORING POINTS, INCLUDING CABLES AND
ANY ACCESSIBLE CONNECTIONS. KEEP ANY HINGES, MOVING
