A-31
Model 199 Differential Pressure Unit Section 5
Table 5.1—Model 199 Parts List
Item Description Part No.
Per
Unit
1 BUA (BELLOWS UNIT ASSEMBLY) SELECT 1
2 HOUSING, PRESSURE, TAPPED (MATCH PORTS WITH
ITEM 3)
1
HOUSING, 1 K SST, 1/4 X 1/4 NPT 9A-CS787-0071C
HOUSING, 1 K SST, 1/4 X 1/2 NPT (TOP/BOTTOM) 9A-CS787-0061C
HOUSING, 1 K SST, 1/2 X 1/4 NPT (TOP/BOTTOM) 9A-C0199-1038C
HOUSING, 1 K SST, 1/2 X 1/2 NPT 9A-CS787-0025Z
HOUSING, 3 K SST, 1/4 X 1/4 NPT 9A-CS787-0066C
HOUSING, 3 K SST, 1/4 X 1/2 NPT (TOP/BOTTOM) 9A-CS787-0057Z
HOUSING, 3 K SST, 1/2 X 1/4 NPT (TOP/BOTTOM) 9A-C0199-1042C
HOUSING, 3 K SST, 1/2 X 1/2 NPT 9A-CS787-0058C
3 HOUSING, PRESSURE, DRILLED (MATCH PORTS
WITH ITEM 2)
1
HOUSING, 1 K SST, 1/4 X 1/4 NPT 9A-CS787-0072C
HOUSING, 1 K SST, 1/4 X 1/2 NPT (TOP/BOTTOM) 9A-CS787-0060C
HOUSING, 1 K SST, 1/2 X 1/4 NPT (TOP/BOTTOM) 9A-C0199-1037C
HOUSING, 1 K SST, 1/2 X 1/2 NPT 9A-CS787-0026Z
HOUSING, 3 K SST, 1/4 X 1/4 NPT 9A-CS787-0067C
HOUSING, 3 K SST, 1/4 X 1/2 NPT (TOP/BOTTOM) 9A-CS787-0056Z
HOUSING, 3 K SST, 1/2 X 1/4 NPT (TOP/BOTTOM) 9A-C0199-1041C
HOUSING, 3 K SST, 1/2 X 1/2 NPT 9A-CS787-0059C
4 BOLT, HOUSING, 1 K 9A-C0199-1345C 12
BOLT, HOUSING, 3 K 9A-C0220-1116J
5 PLUG, PIPE, 1/4"NPT, 316 SST 9A-C0199-0214C 2
PLUG, PIPE, 1/2"NPT, 316 SST 9A-C0199-0215C
6 GASKET, PRESSURE HOUSING, NICKEL 9A-C0199-0184C 2
7 LABEL, HIGH PRESSURE 9A-0199-0194C 1
8 LABEL, LOW PRESSURE 9A-0199-0195C 1
9 BRACKET, MOUNTING, 1 K MODEL 200A/289A 9A-C0199-1493B 1
BRACKET, MOUNTING, 3 K MODEL 200A/289A 9A-CS787-0047Z
BRACKET, MOUNTING, 3 K MODEL 581A 9A-C0199-1109B
10 BRACKET, INDICATOR - MODEL 200A/289A 9A-CS748-0006Z 1
BRACKET, INDICATOR - MODEL 581A 9A-C0197-1019C
11 SPACER, INDICATOR BRACKET - MODEL 200A/289A 9A-C0199-0006C 2
12 SCREW, HEX WASHER HEAD, 3/8-16 X 1-1/8 9A-C0002-1009T 2
13 SCREW, HEX HD, 3/8-16 X 3/4 - MODEL 581A 9A-C0116-0007J 2
14 BRACKET SPACER 9A-C0199-0003C 1
