A-32
Section 5 Model 199 Differential Pressure Unit
Table 5.1—Model 199 Parts List
Item Description Part No.
Per
Unit
15 SCREW, FL HEX SOC CAP HD 3/8-16 X 7/8, ST -
MODEL 200A/289A
9A-C0240-0003J 1
SCREW, FL HEX SOC CAP HD 3/8-16 X 1 -
MODEL 581A
9A-C0240-0004J
16 TAG, S/N, DPU MTG BRK - MODEL 200A/289A 9A-C0199-0002G 1
TAG, S/N, DPU MTG BRK - MODEL 581A 9A-C0224-0003G
17 DRIVE SCREW, RD HD, #0 X 3/16, SS -
MODEL 200A/289A
9A-C0600-1003J 4
DRIVE SCREW, RD HD, #0 X 3/16, SS - MODEL 581A 2
18 SPACER, MOUNTING BRACKET - MODEL 200A/289A 9A-CS787-0008Z 2
19 WASHER, SPLIT LOCK, 3/8, SST 9A-C0003-0093K 5
20 SCREW, CAP HEX HD 3/8-16 X 1-1/2 ST ZP -
MODEL 200A/289A
9A-C0210-0011J 2
21 SCREW, CAP HEX HD 3/8-16 X 1 ST ZP, 1 K -
MODEL 200A/289A
9A-C0210-1007J 2
SCREW, CAP HEX HD 3/8-16 X 3/4 ST ZP, 3 K -
MODEL 200A/289A
9A-C0210-0012J
SCREW, CAP HEX HD 3/8-16 X 3/4 ST ZP, 3 K -
MODEL 581A
9A-C0116-0007J
22 SCREW, CAP HEX HD 3/8-16 X 1 ST ZP -
MODEL 200A/289A
9A-C0210-1007J 1
SCREW, HEX HD, 3/8-16 X 1 - MODEL 581A 9A-C0116-0006J
23 SPACER, CENTER PLATE - MODEL 200A/289A 9A-CS787-0009Z 1
24 SPACER - BLACK EPOXY, 1 K - MODEL 200A/289A 9A-CS787-0006Z 2
25 SPRING PUSH ROD 9A-C0199-0049C 1
26 LOCK NUT, SPRING ADJUST 9A-C0199-0144C 1
27 SPRING RETAINER POST, ROUND, 10-19"WC 9A-C0199-0257C 8
SPRING RETAINER POST, HEX, 20-400"WC 9A-C0199-1337C
28 NUT, SPRING POST, 8-32, ROUND 9A-C0199-0258C 8
NUT, SPRING POST, 6-32, HEX 9A-C0500-0028J
29 SCREW, CALIBRATION SPRING RETAINER, RD HD,
6-32 X 5/16, SST
9A-C0111-0049J 8
30 CALIBRATION SPRING ASSEMBLY, 3-3/4 BELLOWS 1
SPRING ASSY, INC, 0 - 10" WC 9A-C0199-1385B
SPRING ASSY, INC, 0 - 12" WC 9A-C0199-1387B
SPRING ASSY, INC, 0 - 14" WC 9A-C0199-1388B
SPRING ASSY, INC, 0 - 16" WC 9A-C0199-1392B
SPRING ASSY, INC, 0 - 18" WC 9A-C0199-1393B
SPRING ASSY, INC, 0 - 20" WC 9A-C0199-1389B
SPRING ASSY, INC, 20 - 22" WC 9A-C0199-1386B
