Nomenclature
• Reference page numbers are indicated in parentheses.
• In the text, camera controls are indicated by their respective icons.
Focusing screen (→p.127)
Lens mount
Lens mount index (→p.21)
Lens lock pin
Lens release button (→p.21)
Camera back
lock release
button (→p.25)
Camera back
lever (→p.25)
Remote control/Data
transfer terminal
(N3 type)
PC terminal (→p.94)
Power Drive Booster
coupling pin
Reflex mirror (→p.81)
Self-timer lamp (→p.79)
Shutter button (→p.14)
Depth-of-field preview
button (→p.80)
Grip (Battery
chamber) (→p.19)
Grip screw
(→p.19)
Tripod socket
Electrical contacts (→p.7)
Power Drive Booster coupler (cover)
Eyecup (→p.22)
Battery cover
Grip
Battery contacts
Electrical contacts
