Before Using the Machine
Before Using the
Machine
Machine Components
A ADF (Automatic Document Feeder)*
Holds documents and feeds them
automatically into the scanning area.
* MF4150 Only
B Slide guides
Adjust to the width of the document.
C Document feeder tray
Holds documents.
D Document delivery tray
Receives documents.
E Operation panel
Controls the machine.
F Output tray
Receives copies, prints and faxes.
G Paper feeding tray
Loads the paper supply.
H Platen glass cover*
Open this cover when placing a document on
the platen glass.
* MF4122/MF4140 Only
A
G F E
C
B D
H
