Canon imagePROGRAF iPF755 User Manual

Centering originals
Printing Originals Centered on Rolls ............................................................................................................... 153
Printing Originals Centered on Rolls (Windows) ......................................................................................... 153
Printing Originals Centered on Rolls (Mac OS X) ....................................................................................... 155
Printing Originals Centered on Sheets ............................................................................................................ 159
Printing Originals Centered on Sheets (Windows) ...................................................................................... 159
Printing Originals Centered on Sheets (Mac OS X) .................................................................................... 162
Printing Originals Centered on Rolls
You can print originals centered on a page—for example, if the paper is larger than the original, or if you are reducing the
original.
Centering originals relative to roll paper width
If you use originals smaller than the roll paper width, you can center them relative to the width when printing.
Print Centered
Aligns the center of the original with the center of the roll, relative to the width.
For instructions on centering originals when printing on rolls, refer to the following topics, as appropriate for your computer
and operating system.
• Printing Originals Centered on Rolls (Windows) →P.153
• Printing Originals Centered on Rolls (Mac OS X) →P.155
Printing Originals Centered on Rolls (Windows)
This topic describes how to center originals before printing on rolls based on the following example.
• Document: Any type
• Page size: A4 (210.0×297.0 mm)/Letter (8.3 × 11.7 in)
• Paper: Roll
• Paper type: Plain Paper
• Roll width: A3/A4 roll (297.0 mm [11.7 in])
1. Choose Print in the application menu.
2. Select the printer in the dialog box, and then display the printer driver dialog box.(See "Accessing the Printer Driv-
er Dialog Box from Applications (Windows) →P.210 ")
Enhanced Printing Options
> Centering originals >
iPF755 Printing Originals Centered on Rolls
3
153

Canon imagePROGRAF iPF755 Specifications

General

Printer Type	Large Format Printer
Maximum Print Resolution	2400 x 1200 dpi
Number of Ink Colors	5
Number of Nozzles	15, 360
Memory (Standard)	256 MB
Hard Drive	80 GB
Ink Droplet Size	4 picoliters
Operating Systems	Windows, Mac OS
Print Technology	Inkjet
Ink Type	Pigment/Dye
Maximum Print Width	36 inches
Connectivity	USB, Ethernet
Media Handling	Roll Feed
Media Width	8 inches to 36 inches
Media Thickness	0.07 - 0.8mm
Ink Colors	Cyan, Magenta, Yellow, Black
Media Sizes	Roll paper: 10"-36" (254mm-914mm), Cut sheet: 8"-36" (203.2mm-914mm)
Media Types	Plain Paper, Coated Paper, Photo Paper
Power Consumption	140W or less
Print Speed (Color)	D-sized print (33.1 x 23.4 inches) in approximately 28 seconds
Print Speed (Black & White)	D-sized print (33.1 x 23.4 inches) in approximately 28 seconds
