Printing CAD Drawings
Using this printer, you can print fine lines and text clearly and sharply. It's easy to produce highly precise drawings from
CAD applications.
Note
• In Windows, you can print highly precise drawings using the provided imagePROGRAF HDI Driver for Au-
toCAD/AutoCAD LT.
For details on the HDI driver, see the HDI Driver →P.353 .
For instructions on CAD printing, refer to the following topics, as appropriate for your computer and operating system.
• Printing Line Drawings and Text (Windows) →P.19
• Printing Line Drawings and Text (Mac OS X) →P.21
Printing Line Drawings and Text
Printing is easy when you simply choose the type of original to print.
Easy Settings
Simply choose the printing application in the list for optimal printing results.
Print Target
Choose presets that match the type of document to be printed.
Print targets for line drawings and text
Print Target Description
CAD (Color Line Draw-
ing)
Settings optimized to print intricate lines in CAD draw-
ings clearly.
Working With Various Print Jobs > Printing CAD Drawings >
Printing CAD Drawings iPF755
2
18
