Plotter Configuration Editor Dialog Box
The Plotter Configuration Editor dialog box has three sheets.
The Plotter Configuration Editor dialog box display can be manipulated by selecting the items on these sheets or in the
Explorer tree.
Note
• For more details about the General sheet and the Ports sheet, please refer to the AutoCAD manual.
Device and Document Settings Sheet
Use this sheet to perform the main printing settings. The settings for each item are shown in a tree structure on this sheet.
When you select an item the screen display changes so you make changes for the resolution and other graphic settings, the
media type, the color matching and Custom Properties settings, the drying time and the roll paper margin for safety and
other detailed media settings.
The available settings are as follows.
• Media Source and Media Size Settings →P.371
• Graphics Settings →P.372
• Custom Properties dialog box →P.377
Windows Software
> HDI Driver >
Plotter Configuration Editor Dialog Box iPF755
4
370

Canon imagePROGRAF iPF755 Specifications

General

Printer Type	Large Format Printer
Maximum Print Resolution	2400 x 1200 dpi
Number of Ink Colors	5
Number of Nozzles	15, 360
Memory (Standard)	256 MB
Hard Drive	80 GB
Ink Droplet Size	4 picoliters
Operating Systems	Windows, Mac OS
Print Technology	Inkjet
Ink Type	Pigment/Dye
Maximum Print Width	36 inches
Connectivity	USB, Ethernet
Media Handling	Roll Feed
Media Width	8 inches to 36 inches
Media Thickness	0.07 - 0.8mm
Ink Colors	Cyan, Magenta, Yellow, Black
Media Sizes	Roll paper: 10"-36" (254mm-914mm), Cut sheet: 8"-36" (203.2mm-914mm)
Media Types	Plain Paper, Coated Paper, Photo Paper
Power Consumption	140W or less
Print Speed (Color)	D-sized print (33.1 x 23.4 inches) in approximately 28 seconds
Print Speed (Black & White)	D-sized print (33.1 x 23.4 inches) in approximately 28 seconds
